Insta360 Pro 2.0 + Farsight
Insta360 Pro 2 Detailed Specs
Lenses
6 x F2.4 fisheye lenses
Storage
6 x MicroSD cards + 1 x Full SD card
Power
12V 5A adapter
Material
Aluminum alloy
Exposure modes
Auto, Manual, Lens-by-Lens Custom, Shutter Priority (photo only), ISO Priority (photo only)
Diameter
φ143mm
Weight
~1550g
ISO Range
100~6400
Battery Capacity
5100mAh removable battery
White Balance Modes
Auto, Manual
Bitrate per lens
Up to 120Mbps
Video Files
MP4
Video Coding
H264 in-camera, H265 available when post stitching
Video
Post-processing Stitching:
7680 x 3840 @30 fps HDR (8K 2D)
7680 x 7680 @30 fps HDR (8K 3D)
7680 x 3840 @60 fps (8K 2D)
6400 x 6400 @60 fps (6K 2D/3D)
3840 x 3840 @120 fps (4K 2D/3D Binning)
Real-time Stitching:
3840 x 3840 @30 fps (3D)
3840 x 1920@30fps(2D)
4K Live Streaming
Modes: Built-in Server / Custom Server / HDMI output
4K 2D or 3D @30fps
Protocols: RTMP, RTSP, RTMPS, HLS
Simultaneous live streaming + recording for later 8K 3D production
8K Live Streaming
Using Insta360 8K Live*
Modes: Built-in Server / Custom Server / SDI output
8K 2D @30fps
Protocols: RTMP, RTMPS, RTSP
Simultaneous live streaming + recording of stitched 8K live stream
*License and PC required
Video Modes
Standard \ Binning
Note: i-Log is available in all modes and HDR is available in some modes.
Photo Files
JPEG / DNG
Photos
Real-time Stitching
7680 x 7680(3D)
7680 x 3840(2D)
Post-Processing Stitching
7680 x 7680 (3D)
7680 x 3840 (2D)
12000 x 12000 12K Super High-Res
(Multi-Photo Composite) (2D/3D)
Photo Modes
Single shot \ Burst (10 continuous shots) \ Timelapse \
AEB (Auto Exposure Bracket, optional 3, 5, 7, and 9 photos for in-camera HDR photos)
Note: Raw and JPG are both available in all modes
Video Transmission
Insta360 Farsight provides ground-to-ground range of up to 300 meters and ground-to-air range of up to 1000 meters, with 30 FPS preview.
Stabilization
Ultra-precise 9-axis gyroscope
Image Stabilization
FlowState stabilization
Antennae
GPS signal antenna + WiFi signal antenna
GPS
Built-in module
Ethernet Port
Yes
Control software
Windows / Mac / iOS / Android
WiFi specifications
802.11 b/g/n, 2.4GHz. Signal range is about 20 meters in open space. Max preview framerate of 30 FPS, supported in roughly 5-meter range.
Audio
4 Mono Mic
Video Color Space
YUVJ420P, offering a wide color range
Audio coding format
AAC
Spatial audio
Ambisonic
Stitching
Optical Flow / Template
Exposure Range
12 stop
Proxy File
Six low-res proxy files (one per lens) automatically saved in video mode; tailored for smooth editing in Adobe Premiere Pro
Lenses
6 x F2.4 fisheye lenses
Storage
6 x MicroSD cards + 1 x Full SD card
Power
12V 5A adapter
Material
Aluminum alloy
Exposure modes
Auto, Manual, Lens-by-Lens Custom, Shutter Priority (photo only), ISO Priority (photo only)
Diameter
φ143mm
Weight
~1550g
ISO Range
100~6400
Battery Capacity
5100mAh removable battery
White Balance Modes
Auto, Manual
Bitrate per lens
Up to 120Mbps
Video Files
MP4
Video Coding
H264 in-camera, H265 available when post stitching
Video
Post-processing Stitching:
7680 x 3840 @30 fps HDR (8K 2D)
7680 x 7680 @30 fps HDR (8K 3D)
7680 x 3840 @60 fps (8K 2D)
6400 x 6400 @60 fps (6K 2D/3D)
3840 x 3840 @120 fps (4K 2D/3D Binning)
Real-time Stitching:
3840 x 3840 @30 fps (3D)
3840 x 1920@30fps(2D)
4K Live Streaming
Modes: Built-in Server / Custom Server / HDMI output
4K 2D or 3D @30fps
Protocols: RTMP, RTSP, RTMPS, HLS
Simultaneous live streaming + recording for later 8K 3D production
8K Live Streaming
Using Insta360 8K Live*
Modes: Built-in Server / Custom Server / SDI output
8K 2D @30fps
Protocols: RTMP, RTMPS, RTSP
Simultaneous live streaming + recording of stitched 8K live stream
*License and PC required
Video Modes
Standard \ Binning
Note: i-Log is available in all modes and HDR is available in some modes.
Photo Files
JPEG / DNG
Photos
Real-time Stitching
7680 x 7680(3D)
7680 x 3840(2D)
Post-Processing Stitching
7680 x 7680 (3D)
7680 x 3840 (2D)
12000 x 12000 12K Super High-Res
(Multi-Photo Composite) (2D/3D)
Photo Modes
Single shot \ Burst (10 continuous shots) \ Timelapse \
AEB (Auto Exposure Bracket, optional 3, 5, 7, and 9 photos for in-camera HDR photos)
Note: Raw and JPG are both available in all modes
Video Transmission
Insta360 Farsight provides ground-to-ground range of up to 300 meters and ground-to-air range of up to 1000 meters, with 30 FPS preview.
Stabilization
Ultra-precise 9-axis gyroscope
Image Stabilization
FlowState stabilization
Antennae
GPS signal antenna + WiFi signal antenna
GPS
Built-in module
Ethernet Port
Yes
Control software
Windows / Mac / iOS / Android
WiFi specifications
802.11 b/g/n, 2.4GHz. Signal range is about 20 meters in open space. Max preview framerate of 30 FPS, supported in roughly 5-meter range.
Audio
4 Mono Mic
Video Color Space
YUVJ420P, offering a wide color range
Audio coding format
AAC
Spatial audio
Ambisonic
Stitching
Optical Flow / Template
Exposure Range
12 stop
Proxy File
Six low-res proxy files (one per lens) automatically saved in video mode; tailored for smooth editing in Adobe Premiere Pro
