| System | | Main Processor | Embedded processor | | Operating System | Embedded Linux | | Perimeter Protection | | Perimeter Performance AI by Recorder (Number of Channels) | 2 channels | | Face Detection | | Face Attributes | 6 attributes: Gender, age groups (6), glasses, expressions (8), face mask, beard, with up to four detection panels displayed at the same time. | | Face Detection Performance of AI by Recorder (Number of Channels) | 2 channels, and a single channel can detect up to 12 faces. | | Face Recognition | | Face Database Capacity | Up to 10 face databases and 20,000 pictures. | | Face Recognition Performance of AI by Recorder (Number of Channels) | 2 channels | | SMD Plus | | SMD Plus by Recorder | Full-channel SMD Plus (AI by recorder), secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change | | Audio and Video | | Analog Camera Input | 8 channels, BNC: adaptive access by default; HDCVI, AHD, TVI and CVBS access can be configured. | | Camera Input | 1. CVI: 4K, 6MP, 5MP, 4MP, 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps.
2. TVI: 4K, 5MP, 4MP, 3MP, 1080p@25/30, 720p@25/30 fps.
3. AHD: 4K, 5MP, 4MP, 3MP, 1080p@25/30, 720p@25/30 fps. | | IP Camera Input | 8+8 channels, each channel up to 8MP *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled. | | Encoding Capacity | All channel 4K (1 fps–7 fps); 6MP (1 fps–10 fps); 5MP (1 fps–12 fps); 4K-N, 4MP/3MP (1 fps–15 fps); 4M-N/1080p/720p/960H/D1/CIF (1 fps–25/30 fps); | | Dual-stream | Supported (960H (1 fps–15 fps); D1/CIF (1 fps–25/30 fps)). | | Video Frame Rate | PAL: 1 fps–25 fps.
NTSC: 1 fps–30 fps. | | Video Bit Rate | 32 Kbps–6144 Kbps Per Channel | | Audio Sampling | 8 KHz, 16 bit Per Channel | | Audio Bit Rate | 64 Kbps Per Channel | | Bit Rate Type | Video stream and composite stream. | | Video Output | 1 HDMI, 1 VGA
HDMI: 3840 Ч 2160, 1920 Ч 1080, 1280 Ч 1024, 1280 Ч 720
VGA: 1920 Ч 1080, 1280 Ч 1024, 1280 Ч 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable. | | Multi-screen Display | When IP extension mode not enabled: 1/4/8/9
When IP extension mode enabled: 1/4/8/9/16 | | Third-party Camera Access | Onvif, RTSP, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Samsung | | Compression Standard | | Video Compression | AI Coding/H.265+/H.265/H.264+/H.264 | | Audio Compression | G.711A/G.711u/PCM | | Network | | Network Protocol | HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P | | Mobile Phone Access | iPhone, iPad, Android | | Interoperability | ONVIF 16.12, CGI Conformant | | Browser | Chrome, IE9 or above, Firefox | | Network Mode | Single-address mode | | Recording Playback | | Record Mode | Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop | | Recording Playback | 1/4/09 | | Backup Method | USB Device/Network | | Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) | | Storage | | Disk Group | Yes | | Alarm | | General Alarm | Motion detection, Video Loss, tampering, and local alarm | | Anomaly Alarm | No disk, disk error, low space, offline, ip conflict, MAC conflict | | Intelligent Alarm | Face detection, face recognition, perimeter protection | | Alarm Linkage | Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email | | Ports | | Audio Input | 1, RCA (external)
8, BNC (coaxial) | | Audio Output | 1, RCA | | Two-way Talk | Yes (share the same audio input with the first channel) | | HDD Interface | 2 SATA Ports, up to 16TB for a single HDD, the maximum HDD capacity varies with environment temperature | | RS-485 | 1 Port, for PTZ Control | | USB | 2 USB Ports (1 USB 2.0 , 1 USB 3.0) | | HDMI | 1 | | VGA | 1 | | Network Port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) | | General | | Power Supply | DC12V, 4A | | Power Consumption | Lower than 10 W | | Net Weight | 1.59 kg (3.51 lb) | | Gross Weight | 2.76 kg (6.08 lb) | | Product Dimensions | 1U, 375.0 mm Ч 289.0 mm Ч 53.0 mm (W Ч D Ч H)
14.76" Ч 11.38" Ч 2.09" (W Ч D Ч H) | | Packaging Dimensions | 433.0 mm Ч 141.0 mm Ч 366.0 mm (L Ч W Ч H)
17.05" Ч 5.55" Ч 14.41" (LЧ W Ч H) | | Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) | | Operating Humidity | 10%–90% | | Installation | Desktop | | Certifications | CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
FCC: Part 15 Subpart B |
|
