Sky-Watcher offers simple solutions for users who would like to attach their smaller telescope to a convenient computerized system but do not wish to deal with the weight of the HEQ5 or EQ6 mount. The EQ5 Pro mounts use the same Go-To system found in the HEQ5 and EQ6 Pros-- SynScan. It allows you to point the telescope at a specific object or even tour the skies at the touch of a button.
The EQ5 SynScan mounts are the perfect instrument for novice visual observers to enjoy astronomy with minimal setup time and in-depth knowledge of the night sky. For novice users, the user-friendly menu allows automatic slewing to 42900+ objects.
Main advantages
• Positioning Accuracy up to 1 arc minute. Accuracy enhanced by software collimation error (mount mechanical error) compensation.
• Stepper motors with 1.8° step angle and 32 micro steps driven.
• Slewing speed up to 3.4°/sec (800X).
• Guiding speed selectable from 0.25X, 0.50X, 0.75X, or 1X.
• Object database containing complete Messier, NGC, and IC catalogues.
• Periodic Error Correction.
• PC compatibility.
• Upgradeable hand control via internet download.
|
| Controllable via PC: | Jā | | Controllable via PC: | Да | | Controllable via PC: | Да | | Updateable via web: | Jā | | Updateable via web: | Да | | Updateable via web: | Да | | Pole finder: | Jā | | Pole finder: | Да | | Pole finder: | Да | | Backlash compensation: | Jā | | Backlash compensation: | Да | | Backlash compensation: | Да | | Periodic error correction: | Jā | | Periodic error correction: | Да | | Periodic error correction: | Да | | Datu bāze: | 42.900 objekti | | База данных: | 42.900 oбъекты | | Database: | 42.900 objects | | Programmatūra | SynScan | | Программного обеспечения: | SynScan | | Software: | SynScan | | NGC: | Jā | | NGC: | Да | | NGC: | Да | | Noregulēšanas metode: | 1 - zvaigžņu Align, 2 - zvaigžņu Align, 3 - zvaigžņu Align | | Метод регулировки: | 1 – звезды Align, 2 – звезды Align, 3 – звезды Align | | Alignment method: | 1 - Star Align, 2 - Star Align, 3 - Star Align | | Messier: | Jā | | Messier: | Да | | Messier: | Да | | IC: | Jā | | ИC: | Да | | IC: | Да | | Izsekošanas ātrums: | Zvaigznes, Saules un Mēness | | Скорость слежения: | Звёздная, Солнечная и Лунная | | Tracking speeds: | Sidereal, Solar and Lunar | | Precizitāte: | 1 | | Точность | 1 | | Precision: | 1 | | GoTo valoda: | Angļu | | Язык GoTo: | Aнглийский | | GoTo language: | English | | Interfeiss: | ST-4 type Autoguider | | Интерфейс | ST-4 type Autoguider | | Interfaces: | ST-4 type Autoguider | | Position precision: | 60 | | Position precision: | 60 | | Position precision: | 60 | | Guiding speeds: | 0.25x, 0.50x, 0.75x, 1x, 2.0x, 16x, 32x, 64x, 128x, 400x, 500x, 600x, 800x | | Guiding speeds: | 0.25x, 0.50x, 0.75x, 1x, 2.0x, 16x, 32x, 64x, 128x, 400x, 500x, 600x, 800x | | Guiding speeds: | 0.25x, 0.50x, 0.75x, 1x, 2.0x, 16x, 32x, 64x, 128x, 400x, 500x, 600x, 800x | | Caldwell: | Jā | | Caldwell: | Да | | Caldwell: | Да | | Pointing accuracy: | Līdz 1 arc min | | Pointing accuracy: | До 1 arc min | | Pointing accuracy: | Up to 1 arc min | | Materiāls: | Tērauds | | Mатериал: | Cталь | | Material: | Steel | | Maksimālais augstums (cm): | 121 | | Максимальная высота (см): | 121 | | Max. height (cm): | 121 | | Svars (kg): | 5.6 | | Вес (кг): | 5.6 | | Weight (kg): | 5.6 | | Tips: | Ekvatoriāls | | Тип: | Экваториальный | | Type: | Equatorial | | Apzīmējums: | EQ5 | | Обозначение: | EQ5 | | Title: | EQ5 | | Maksimālā slodze (kg): | 10 | | Максимальная нагрузка (кг): | 10 | | Max. additional load capacity (kg): | 10 | | Counterweight(s) (piece): | 1 (5.1kg) | | Counterweight(s) (piece): | 1 (5.1кг) | | Counterweight(s) (piece): | 1 (5.1kg) | | Diameter of counterweight bar (mm): | 18 | | Diameter of counterweight bar (mm): | 18 | | Diameter of counterweight bar (mm): | 18 | | Power requirement: | 11 līdz 15 V DC 2A | | Power requirement: | 11 до 15 V DC 2A | | Power requirement: | 11 to 15 V DC 2A |
|
