| OpenCL version | 3.0 |
| Launch date | Q1'24 |
| Status | Launched |
| Processor socket | LGA 1700 |
| Bus type | DMI4 |
| Processor model | i5-14500 |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor operating modes | 64-bit |
| Processor cache type | Smart Cache |
| Processor threads | 20 |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Processor cores | 14 |
| Processor cache | 24 MB |
| Box | Да |
| Processor codename | Raptor Lake |
| Processor boost frequency | 5 GHz |
| Maximum number of DMI lanes | 8 |
| Efficient-core boost frequency | 3.7 GHz |
| Processor base power | 65 W |
| Efficient-core base frequency | 1,9 GHz |
| Efficient cores | 8 |
| Performance cores | 6 |
| Performance-core boost frequency | 5 GHz |
| Performance-core base frequency | 2,6 GHz |
| Maximum turbo power | 154 W |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b |
| Discrete graphics card model | Not available |
| On-board graphics card | Да |
| Number of execution units | 32 |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
| On-board graphics card dynamic frequency (max) | 1550 MHz |
| Number of displays supported (on-board graphics) | 4 |
| Discrete graphics card | Нет |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
| On-board graphics card OpenGL version | 4.5 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Maximum number of PCI Express lanes | 20 |
| Embedded options available | Да |
| Supported instruction sets | AVX 2.0 |
| Execute Disable Bit | Да |
| PCI Express slots version | 5.0 |
| PCI Express configurations | 1x16+1x4 |
| Idle States | Да |
| Thermal Monitoring Technologies | Да |
| Market segment | Desktop |
| Direct Media Interface (DMI) Revision | 4.0 |
| Use conditions | PC/Client/Tablet |
| Memory bandwidth (max) | 76.8 GB/s |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory channels | Dual-channel |
| Tjunction | 100 °C |
| Processor package size | 45 x 37.5 mm |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Да |
| Intel® Boot Guard | Да |
| Intel Virtualization Technology for Directed I/O (VT-d) | Да |
| Intel Virtualization Technology (VT-x) | Да |
| Intel® Active Management Technology (Intel® AMT) | Да |
| Intel® Secure Key | Да |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Да |
| Intel® AES New Instructions (Intel® AES-NI) | Да |
| Intel 64 | Да |
| Intel Trusted Execution Technology | Да |
| Intel® vPro™ Platform Eligibility | Да |
| Intel VT-x with Extended Page Tables (EPT) | Да |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Да |
| Intel Stable Image Platform Program (SIPP) | Да |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | Да |
| Enhanced Intel SpeedStep Technology | Да |
| Intel® Threat Detection Technology (TDT) | Да |
| Intel vPro® Enterprise Platform Eligibility | Да |
| Intel® Remote Platform Erase (RPE) | Да |
| Intel® Hardware Shield Eligibility | Да |
| Intel® OS Guard | Да |
| Intel® Total Memory Encryption - Multi Key | Да |
| Intel® One-Click Recovery | Да |
| Intel® Thread Director | Да |
| Intel® Standard Manageability (ISM) | Да |
| Intel vPro® Essentials Platform Eligibility | Да |
| Intel® Volume Management Device (VMD) | Да |
| Intel® Control-flow Enforcement Technology (CET) | Да |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Да |
| Intel® Speed Shift Technology | Да |
| Intel® Deep Learning Boost (Intel® DL Boost) | Да |
| Intel Turbo Boost Max Technology 3.0 | Нет |
| Mode-based Execute Control (MBE) | Да |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Maximum internal memory | 192 GB |
