| Launch date | Q3'21 |
| Status | Launched |
| Supported memory types | DDR4-SDRAM |
| Processor base frequency | 3.1 GHz |
| Processor cache | 8 MB |
| Processor boost frequency | 4.6 GHz |
| Processor manufacturer | Intel |
| Processor operating modes | 64-bit |
| Processor threads | 4 |
| Thermal Design Power (TDP) | 65 W |
| Processor cores | 4 |
| Processor model | E-2324G |
| Processor cache type | Smart Cache |
| Processor family | Intel Xeon E |
| Box | N |
| Processor socket | LGA 1200 (Socket H5) |
| Processor lithography | 14 nm |
| Component for | Server/workstation |
| System bus rate | 8 GT/s |
| Cooler included | N |
| On-board graphics card | Y |
| Discrete graphics card model | Not available |
| Number of execution units | 32 |
| Discrete graphics card | N |
| On-board graphics card model | Intel UHD Graphics P750 |
| On-board graphics card 4K support | Y |
| On-board graphics card dynamic frequency (max) | 1300 MHz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card base frequency | 350 MHz |
| Commodity Classification Automated Tracking System (CCATS) | G167599 |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| PCI Express configurations | 1x8+3x4 |
| Maximum number of PCI Express lanes | 20 |
| CPU configuration (max) | 1 |
| PCI Express slots version | 4.0 |
| Thermal Monitoring Technologies | Y |
| Harmonized System (HS) code | 8542310001 |
| Market segment | Server |
| Supported instruction sets | AVX 2.0 |
| Idle States | Y |
| Execute Disable Bit | Y |
| Scalability | 1S |
| ECC | Y |
| Memory channels | Dual-channel |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Tjunction | 100 °C |
| Processor package size | 37.5 x 37.5 mm |
| Intel® Transactional Synchronization Extensions | N |
| Intel® Turbo Boost Technology 2.0 frequency | 4.6 GHz |
| Intel® Hyper Threading Technology (Intel® HT Technology) | N |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Clear Video Technology | Y |
| Intel Trusted Execution Technology | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Secure Key | Y |
| Intel® Quick Sync Video Technology | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® InTru™ 3D Technology | Y |
| Maximum Enclave Size Support for Intel® SGX | 0.5 GB |
| Intel Software Guard Extensions (Intel SGX) | Y |
| Intel® Optane™ DC Persistent Memory Supported | N |
| Intel® Memory Protection Extensions (Intel® MPX) | Y |
| Intel® Boot Guard | Y |
| Intel® vPro™ Platform Eligibility | Y |
| Intel® OS Guard | Y |
| Intel 64 | Y |
| Maximum internal memory | 128 GB |
