Pioneer TS-W3010PRO
| The Pioneer Reference Series for Open Show series of speakers is designed specifically for those looking to produce some serious sound pressure levels. Inspired by Pioneer’s history of record-breaking SPL competition, the new PRO series line of speakers is designed for loud sound pressure levels for open shows. PRO Samurai series TS-W3010PRO subwoofer has a nominal power 1500 W and double voice coil. The wide stitched-reinforced urethane surround provides long cone stroke and a secure fit at high volumes. The 4-layer copper-clad aluminum voice coil allows to achieve weight reduction and high sensitivity. The high quality steel basket construction dissipates heat away from the voice coil. Big double magnet provides high power. Main Features Shuriken PRO Pioneer Reference for Open Show Size 30 cm Type Subwoofer Maximum power 1500 W Continuous power output 600 W Frequency response 20 Hz to 200 Hz (In-Car) Sensitivity 90 (1 W/In-car) dB Impedance 1 Ω or 4 Ω Dual Voice Coil (DVC) Mounting Depth 142 mm Woofer Cut-Out Hole Φ282 mm Woofer material Paper Surround Urethane Spider Polyester Fibre Voice Coil type 4-layer Long Copper Voice Coil bobbin type Aluminium Terminals Push Magnets Ferrite 30cm / 12″ Recom. Enclosure [l] 35 (Sealed Enclosure) 50 (Ported Enclosure) Recom. Enclosure [ft3] 1.24 (Sealed Enclosure) 1.77 (Ported Enclosure) Weight 7.1 (Excluding accessories) kg Dimensions Φ322 x 166 mm Accessories Subwoofer mounting screws Thiele/Small Parameters Qts 0.84 Fs [Hz] 35.7 Hz Vas [ft3] 8.86 Vas [l] 24.3 Xmax [mm] 15 |
